Solid State Relays and Magnetic Sensors for the Medical Industry

Create high reliability in your healthcare equipment with Long Lasting and Safe components

Your equipment dedicated to the medical industry should offer precision, reliability and quiet operation.
The ideal choice to this challenge: celduc® relais’ solutions

celduc® relais is a long-standing partner to the Medical industry, we offer a wide range of Solid State Relays and Magnetic Proximity Sensors to meet the requirements of this strongly regulated market.

Some of our products fulfil the requirements for medical applications according to EN 60601-1 (VDE 0750).

Some examples of medical applications :

Hospital-bed-Hospital beds

Several motors are used for an adjustable hospital bed to produce a desired bed configuration. Our PCB Solid State Relays are used to control these motors.
Key products : PCB Solid State Relays


-Dialysis Machines

The SSR is used to heat the fresh dialyzing solution coming from a tank but also to regulate blood temperature and detergents during the cleaning cycle.
Key products : Four-Leg Solid State Relays

-Neonatal incubators / Patient temperature management

Incubators and warmers are used to maintain the body temperature of newborn infants and patients. Our Solid State Relays are used for heating resistance control.
Key products : 22,5mm pitch single Phase Solid State Relays

-Medical Refrigeration Medical-Refrigeration

When storing blood, vaccines or medicines …. supervising the opening of doors in medical/laboratiry fridges is a mandatory. Our Reed sensors are very reliable and will operate over millions of cycles with long-term integrity
Key products : Tubular magnetic sensors

-Laboratory Sterilizers

In sterilizer autoclave for medical industry, Solid State Relays are used for chamber heating as well as for steam generator.
Key products : 45mm pitch three-phase Solid State Relays

-Laboratory Glassware washers / Desinfectors

In the medical industry Laboratory Glassware washers / Desinfectors should provide superior cleaning and disinfection combined with innovative options to minimize cost and time. Our Solid State Relays are used for heating control.
Key products : “Ready to use” 22,5mm pitch single phase SSR

-Blood Analyser / CentrifugesBlood-Analyser-Centrifuges

In this equipment, you can use our Solid State Relays for heating resistance control and our safety sensors for machines safety to protect the operators against contaminations.
Key products : Safety sensors

Dentist-Table-Dentist table

In dentist tables, up to 6 motos could be used to adjust the different positions of the seat and the armrest. Our extensive range of PCB solid state relays are the proper solutions to control these motors that demand long life and high reliability.
Key products : PCB Solid State Relays

-Dental laboratory ovensDental-laboratory-oven

Dental Laboratory Furnaces are used for Ceramic or Porcelain Firing & Pressing. Temperature uniformity and High temperature accuracy of +/-1 °C inside the round chamber is very important. Celduc® relais‘ SSRs are the right choice for accurate and long life time temperature control. Solid State Relays have a very high frequency switching compare to Electro-Mechanical Relays. In temperature control, low switching frequency limits the accuracy.
Key products : EMC optimised SSR


-Process for medicines’ manufacturing & packaging

Our products are used for heating and process control in complete lines for production of pharmaceutical products and in packaging lines for drugs / pills packaging. You can also read our dedicated brochure « Packaging Industry by celduc® relais »


-Auxiliary equipment & accessories

There are numerous other applications for our products : Reed switches for Syringe pumps ; magnetic proximity sensor in Arthroscopy equipment ; DC reversing switches in Endoscope washer-disinfector ; sensors for Healthcare automation for hospitals,

celduc’s solutions are displayed in our brochure MEDICAL INDUSTRY by celduc relais
